Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Milled Aluminium
Primary Lens PMMA
Primary Reflector PC metallised
Secondary Reflector -
Body Finish White,Black,Custom
Diffuser -
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Adjustable
Tilt Yes
Swivel No
Electrical System
Driven with Constant Current Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Remote
LED Power Watts 3.6W
System Power Watts 4.5W
Operating Voltage Vin 220-240 Vac
Power Factor p.f. > 0.5
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI90
Led Type SMD mid power
LED Fitted CREE COB LED 36Vdc/130mA
Controls
Standard Switchable On/Off
Optional PDIM,DDIM,Non Dimmable
Light Distribution
Ordering Details
Code Example:
| Name | Watt | CCT | CRI | Angle | Finish | Control |
|---|---|---|---|---|---|---|
| Dot DM | 5W | WW27K | CRI90 | 32°(MD) | SWH | On/Off |
Select one from each column with highlighted values to create the ordering code
| NAME | WATT | LUMEN | EFFICACY | CCT | CRI | ANGLE | FINISH | CONTROL | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Dot DM | 5W | 320 | 71 | 2700K | WW27K | CRI90 | 32°(MD) | White | SWH | Non Dimmable | On/Off |
| 329 | 73 | 3000K | WW30K | Black | SBL | Phase Dimmable | PDIM | ||||
| 347 | 77 | 4000K | NW40K | Custom | CSM | Dali Dimmable | DDIM | ||||
| 356 | 79 | 5700K | CW57K | ||||||||
| Dot DM | 5W | WW27K | CRI90 | 32°(MD) | SWH | On/Off | |||||
